产品介绍：
用途：
本产品主要用作交流额定电压为500V及以下的冰箱、压缩机、风力发电等电机绕组引接线。具有良好的耐制冷剂、耐溶剂和耐环境应力等特性。
Usage:
This product is mainly used as the rated voltage is 500V and below the refrigerator, compressor, motor winding connection of wind power. Has a good resistance to refrigerants,solvent resistance and resistance to environmental stress and other characteristics.
耐氟利昂电机绕组引接软线
Freon resistant motor winding connection soft wire
执行标准 standard：JB/T 6213.5-2006
型号 type 名称 name
JZ 聚酯绝缘耐氟利昂电机绕组引接软线
Polyester insulation resistance to freon motor winding connection soft wire
JF46 聚全氟乙丙烯绝缘耐氟利昂电机绕组引接软线
Poly-fluorinated ethylene propylene freon motor winding resistance soft wire
使用特性
额定电压：交流500V
JZ型电缆（电线）的连续运行导体温度为：120℃
JF46型电缆（电线）的连续运行导体温度为：200℃
电缆敷设时允许弯曲半径不小于电缆外径的4倍。
Features:
related voltage:AC 500V
The continuous operating temperature of JZ type cable（wire) is 120℃
The continuous operating temperature of JF46 type cable (wire) is 200℃
The bending radius is not be less than 4 times of the cable when installation
JZ、JF46电缆产品参数表
JZ 、JF46 type cable parameter
|
标称截面积 mm2 Nominal section area |
绝缘标称厚度 Mm Nominal thickness |
平均外径上限 Mm Upper limit OD |
||
|
JZ |
JF46 |
JZ |
JF46 |
|
|
0.5 |
0.45 |
0.4 |
1.90 |
1.80 |
|
0.75 |
0.45 |
0.4 |
2.10 |
2.00 |
|
1 |
0.45 |
0.4 |
2.30 |
2.20 |
|
1.25 |
0.45 |
0.4 |
2.45 |
2.30 |
|
1.5 |
0.60 |
0.4 |
2.90 |
2.45 |
|
2 |
0.60 |
0.5 |
3.10 |
3.00 |
|
2.5 |
0.60 |
0.5 |
3.30 |
3.10 |
